ISO 17699 DIN53333 Leather Tester For Water Vapour Permeability

ISO 17699 DIN53333 Leather Tester For Water Vapour Permeability

ISO 17699 DIN53333 Leather Tester For Water Vapour Permeability

Brand Name:	HAIDA
Model Number:	HD-P835
MOQ:	1 Set
Price:	Negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability:	30 Sets per Month Haida

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China (Mainland)

Certification:

CE,ISO

Power:

Electronic

Inner Capacity:

50*50*60cm (L X H X D)

Cooling Speed:

1°C /min At Ave

Compressor:

France Tecumseh

Sample Size:

34mm

Bottle mouth diameter:

30mm

Test Plate Speed:

(75±5)CPM

Blade Angel:

120 Degrees

Packaging Details:

ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man

Supply Ability:

30 Sets per Month Haida

Highlight:

ISO 17699 Leather Tester

,

DIN53333 Leather Tester

,

DIN53333 Water Vapour Permeability Tester

Product Description

ISO 17699 DIN53333 Textile Leather Water Vapour Permeability Tester 50 x50x60cm

PRODUCT DISCRIPTION

This machine is mainly use to test water resistant vapor permeability characteristic for vamp and upper shoe materials ( including surface and lining) Under the standard stipulated 20℃ and the 65%RH environment

Test STANDARD

DIN53333,ISO 8782-1,ISO 17699

STANDARD FEATURES

Model	HD-P835
Temperate and humidity range	20℃, 65%RH
Material	Stainless steel SUS#304
Inner capacity	505060cm (L x H x D)
Safety device	thermal ,overheat, overload protection
Temp Accuracy,uniformity	within 0.5°C,within 1°C
Cooling speed	1°C /min at ave.
Refrigerant	R404 with environment protection
Compressor	France Tecumseh
Compressor start delay time	5min
Control ways	TEMI 880 controller, touch screen control
Sample size	34mm
Bottle mouth diameter	30mm
Fan size	90x75mm(LxW)
Test plate speed	(75±5)CPM
Blade angel	120 degrees
Fan Blade Nos.	3pcs
Fan speed	(1400±100) rpm.
Voltage	AC220V,10A

ISO 17699 DIN53333 Leather Tester For Water Vapour Permeability 0
