Tensile Testing Machine
Created with Pixso.

5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber

5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber

5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber

Brand Name: haida
MOQ: 1
Price: €3,493.80
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Accuracy:
±0.1% ~ ±0.5% FS
Frame Capacity:
2000kg
Load Accuracy:
0.5% F.S
Control System:
PC With Windows 7 System
Motor:
Pana.sonic Servo Motor W/AC Variable Speed Drive System
Force Reading:
Kgf, Ibf, N, KN, T Etc
Vertical Test Space:
1200mm Including Fixture
Horizontal Test Space:
≤400mm
Test Speed:
0.1~500mm/min (adjustable)
Curves Display:
Load-elongation, Elongation-time, Time-elongation, Stress-strain
Data Display:
Max. Force, Speed, Sample Information, Strength(Kpa, Mpa, N/mm, N/mm2) Etc…
Safety Features:
E-Stop, Over-load Protection, Upper And Lower Limit Switches, Load Sensor With Automatic Retreat
Voltage:
220 V
Software:
TM 2101
Load Cell Brand:
Germany Brand Load Cell For High Accuracy, 2000kg (500,1000kg Are Optional)
Highlight:

digital display tensile testing machine

,

pulling force tester for plastic rubber

,

2000kg capacity tensile strength tester

Product Description
5-2000kg Digital Force Testing Equipment
5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 0 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 1
Product Overview
The Computerized Universal Testing Machine is designed for comprehensive mechanical property testing of various materials. This advanced equipment performs static load, tensile, compression, bending, shearing, tearing, and peeling tests with exceptional precision.
Applications
Ideal for testing plastic plates, pipes, profiles, plastic films, rubber, wires, cables, steel, fiberglass, and other industrial materials. Developed specifically for material research and quality control applications.
Technical Specifications
Frame Capacity 2000kg (500kg, 1000kg optional)
Load Cell German brand for high accuracy
Load Accuracy 0.5% F.S
Control System PC with Windows 7 system
Motor Panasonic servo motor with AC variable speed drive system, high-precision mechanical ball screw rod
Force Reading kgf, lbf, N, KN, T etc
Vertical Test Space 1200mm including fixture
Horizontal Test Space ≤400mm
Test Speed 0.1~500mm/min (adjustable)
Software TM 2101
Data Display & Analysis
  • Curves display: Load-elongation, Elongation-time, Time-elongation, Stress-strain
  • Data parameters: Maximum force, speed, sample information, strength (Kpa, Mpa, N/mm, N/mm²)
  • Comprehensive reporting: Word/Excel reports with results for maximum force, elongation, tensile strength, peel strength, tear strength, compression strength
Testing Capabilities
  • Materials: Laminated materials, wood, leather, rubber & plastic, metal materials
  • Test types: Tensile, peel, tear, heat seal, adhesive, bend and open force with different grips
  • Deformation under defined load testing
  • Load under defined deformation testing
Safety Features
  • Emergency Stop (E-Stop)
  • Over-load protection
  • Upper and lower limit switches
  • Load sensor with automatic retreat
5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 2 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 3 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 4 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 5 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 6 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 7
Customized Fixtures
Haida provides comprehensive fixture customization services to meet all customer testing requirements and specific material testing needs.
5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 8 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 9
Tensile Testing Applications
5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 10 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 11 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 12 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 13 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 14 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 15 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 16 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 17
Manufacturer Profile
5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 18 5-2000kg Sensor Digital Display Pulling Force Testing Equipment Pull Tester Tensile Strength Testing Machine for Plastic Rubber 19
Why Choose Haida Equipment?
  • Considerate Service: Different country plugs, manual voltage change from 110V to 220V, insurance indicator
  • Excellent After-Sales Service: 12 months warranty with free problem controller repair assistance
  • Free replacement parts, even for components not from our factory
  • Comprehensive support: Operation videos and English operation manual
  • Video conference support available
Please feel FREE to contact us if you have any needs. And welcome to visit our OFFICIAL WEBSITE at:
www.haidatestequipment.com
If you want to know more information...
Please leave a message below and click "CONTACT SUPPLIER"
Thanks for your time and attention!
