0.32m/Sec Pilling Test Machine Rubber Abrasion Tester 70×30×30cm

Basic Information
Place of Origin: Guangdong, China (Mainland)
Brand Name: HAIDA
Certification: CE,ISO
Model Number: HD-P307
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 30 Sets per Month Haida
Detail Information
Power: Electronic Specimens Size: 16mm, 6-15mm (D)
Weight Load: 2.5N,5N Wheel Diameter: 150mm
Wheel Length: 460mm Abrasion Speed: 0.32m/sec
Machine Size: (L×W×H)70×30×30cm Net Weight: 55KG
High Light:

0.32m/Sec Pilling Test Machine


70×30×30cm Pilling Test Machine


ASTM Rubber Abrasion Tester

Product Description

0.32m/Sec Pilling Test Machine Rubber Abrasion Tester 70×30×30cm




Key Specification


Technical Index HD-P307
Specimens size 16mm, 6-15mm (D)
Fixture load 2.5N
Weight load 2.5N,5N
Fixture lateral displacement 4.2mm/wheel each lap
Wheel diameter 150mm
Wheel length 460mm
Wheel rotate speed 40rpm
Travel reservations 40m/20m
Abrasion speed 0.32m/sec
Dip angle 3°the angle of the specimen
back shaft with vertical roller face
Machine Size (L×W×H)70*30*30
Net Weight 55KG






















DIN Abrasion Tester is to test the friction of surface by a particular piece of sandpaper, After
friction for a certain time, and then assess the condition of material surface, weight, volume and thickness,
from this standard to assess the abrasive nature of materials.
This DIN Abrasion Tester is a high efficiency, good reproducibility and easy to operate,
applied to test the abrasive nature of material, as such elastic material, rubber, tires, convey belt, transmit
belt, sole, synthetic leather, leather and others.
DIN Abrasion Tester applied to test leather performance in shoes, clothing, luggage handbag
industry, research laboratories; commodity inspection, arbitration and technical supervision departments




Standard Features


DIN-53516, ISO-4649, GB/T9867, ASTM D5963, ISO 20344 8.3
