| Place of Origin: | Guangdong, China (Mainland) |
|---|---|
| Brand Name: | HAIDA |
| Certification: | CE,ISO |
| Model Number: | HD-W272 |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man |
| Delivery Time: | 20 days after order confirmed |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow |
| Supply Ability: | 30 Sets per Month Haida |
| Power: | Electronic | Dosing Amount: | 0.1~10.0ml |
|---|---|---|---|
| Operating Speed: | 0 ~ 400mm / Min | Dimension: | 510*360*550mm |
| Weight: | 35kg | Supply: | AC220V 50Hz 50W |
| Use: | Tissue | Product Name: | Absorption Rate Tester |
| Highlight: | 400mm/Min abrasion testing machine,50W abrasion testing machine,50W abrasion resistance tester |
||
400mm/Min 50W Abrasion Testing Machine , Abrasion Resistance Tester For Tissue
Application
Absorption Rate Tester for absorption rate of various sanitary napkins, pads, etc.
Technical parameters
| Technical Index | HD-W272 |
| Dosing amount | 0.1~10.0ml |
| Standard test module | 76±1mm*80±1mm, mass is 127.0±2.5g |
| Curved sample holder | Length: 230 ± 1mm, Width:80 ± 1mm |
| Dosing speed | ≥1.7mL/s (meeting standard dosing 5.0mL in 3s) |
| The operating speed of the filling port | 0 ~ 400mm / min |
| Dimension | 510*360*550mm |
| Weight | 35kg |
| Power | AC220V 50Hz 50W |
Testing standard
GB/T 8939-2018
FAQ
How to install and use the product?
The product is shipped with an operating instructions and video of English version.or we will send you an operation video to teach you how to install and use the product with English speaking. However, if you need us to teach you face to face, please let us know in advance.
How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing - delivery - customer receiving - after service.
