Abrasion Paper Pilling Test Device For Textiles Testing

Basic Information
Place of Origin: Guangdong, China (Mainland)
Brand Name: HAIDA
Certification: ISO,CE
Model Number: HD-P304
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 80 Sets per Month
Detail Information
Load: 250gx2,500gx2, 750gx2 Net Weight: 40Kg
Dimension: 45×35×42cm Power: AC220V/50Hz
Speed: 60~72r/min(adjustable) Thickness: 12.7mm
High Light:

Abrasion Paper Pilling Test Device


Textiles Pilling Test Device

Product Description

Product Description:

The Pilling Test Device, also known as the Pilling Tester Machine or Pilling Test Instrument, is an advanced piece of equipment designed to evaluate the pilling characteristics of fabric and other materials. It features two abrasion wheels with a space of 52.5mm between them, and a net weight of 40kg. It also has a dimension of 45×35×42cm, and it provides the option of using abrasion paper (S-42, width 12.7mm, length 160mm) to further evaluate pilling performance. This versatile device is perfect for use in laboratories and other research centers, and it is suitable for a wide range of materials and fabrics.



  • Product Name: Pilling Test Machine
  • Load: 250gx2, 500gx2, 750gx2
  • Counter: LED 0~99999999
  • Abrasion Wheel and Plate's Space: 37~38mm
  • Net Weight: 40Kg
  • Pilling Test Facility
  • Pilling Test Instrument
  • Pilling Test Device
  • Pilling Test System
  • Pilling Test Machine

Technical Parameters:

Parameter Value
Net Weight 40Kg
Space Between Abrasion Wheels 52.5mm
Load 250gx2, 500gx2, 750gx2
Dimension 45×35×42cm
Counter LED 0~99999999
Rotating Speed 60~72r/min(adjustable)
Power Supply AC220V/50Hz
Thickness of Abrasion Wheel 12.7mm
Abrasion Paper (Optional) S-42, width 12.7mm, length 160mm
Abrasion Wheel and Plate's Space 37~38mm


Abrasion Tester is suitable for measuring leather, fabric, coating, paper, floor tile, plywood, glass, natural rubber, etc. . Use the specified grinding wheel and apply the weight to the specimen cut with the knife. Set the scroll time. Then take out the specimen and observe the condition after the specimen is worn. Or calculate the different weights of the samples before and after the test to get the wear index meter.


Support and Services:

At Pilling Test Machine, we provide technical support and services to our customers. Our team of experienced professionals is available to answer any questions or concerns you may have about our products. We offer a variety of services, including installation, maintenance and repair, as well as troubleshooting and product usage support. We also provide training and education to ensure our customers have the necessary skills to get the most out of their Pilling Test Machine. Our team is committed to providing the highest level of customer service and satisfaction.

Abrasion Paper Pilling Test Device For Textiles Testing 0

Packing and Shipping:

Packaging and Shipping for Pilling Test Machine:

  • The Pilling Test Machine shall be packed in a waterproof carton.
  • The carton should be labeled with the product name and shipping address.
  • The product should be securely fastened to the carton to prevent movement during shipment.
  • The product should be checked for damages before shipping.
  • The product should be shipped using a reliable shipping company.


Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 12 years focusing on test equipment field,6 years exporting experience.

Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.

Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 12 months by HAIDA,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.

Q:What about the product' services and quality?
A:Each equiopment must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer's company when you need. products are widely recognized and trusted by users.
A :Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.

Q: Can your products be customized?
A: Yes, our product can be customized according to your parameters.
